0x000E - Docker-Compose budibase Example

0x000E - Docker-Compose budibase Example

CouchDB install is  simply a docker-compose.yml file as: link

version: '3'
services:
  couchserver:
    image: couchdb
    restart: always
    ports:
      - "5984:5984"
    environment:
      - COUCHDB_USER=admin
      - COUCHDB_PASSWORD=YOURPASSWORD
    volumes:
        - ./dbdata:/opt/couchdb/data

And to activate it:

docker-compose up

To test if it works in a browser:

ip:5984

Giving us:

{"couchdb":"Welcome","version":"3.2.2","git_sha":"d5b746b7c","uuid":"1dc33059f35164d1cc6ae8c65b224b25","features":["access-ready","partitioned","pluggable-storage-engines","reshard","scheduler"],"vendor":{"name":"The Apache Software Foundation"}}

Budibase:

  • Budibase is a powerful form filling engine.
  • Fill in the .env files
# Use the main port in the builder for your self hosting URL, e.g. localhost:10000
MAIN_PORT=10000

# This section contains all secrets pertaining to the system
# These should be updated
JWT_SECRET=testsecret
MINIO_ACCESS_KEY=budibase
MINIO_SECRET_KEY=budibase
COUCH_DB_PASSWORD=budibase
COUCH_DB_USER=budibase
REDIS_PASSWORD=budibase
INTERNAL_API_KEY=budibase

# This section contains variables that do not need to be altered under normal circumstances
APP_PORT=4002
WORKER_PORT=4003
MINIO_PORT=4004
COUCH_DB_PORT=4005
REDIS_PORT=6379
WATCHTOWER_PORT=6161
BUDIBASE_ENVIRONMENT=PRODUCTION

# An admin user can be automatically created initially if these are set
BB_ADMIN_USER_EMAIL=
BB_ADMIN_USER_PASSWORD=

# A path that is watched for plugin bundles. Any bundles found are imported automatically/
PLUGINS_DIR=

A Example Docker-compose

version: "3"

# optional ports are specified throughout for more advanced use cases.

services:
  app-service:
    restart: unless-stopped
    image: budibase.docker.scarf.sh/budibase/apps
    container_name: bbapps
    environment:
      SELF_HOSTED: 1
      COUCH_DB_URL: http://${COUCH_DB_USER}:${COUCH_DB_PASSWORD}@couchdb-service:5984
      WORKER_URL: http://worker-service:4003
      MINIO_URL: http://minio-service:9000
      MINIO_ACCESS_KEY: ${MINIO_ACCESS_KEY}
      MINIO_SECRET_KEY: ${MINIO_SECRET_KEY}
      INTERNAL_API_KEY: ${INTERNAL_API_KEY}
      BUDIBASE_ENVIRONMENT: ${BUDIBASE_ENVIRONMENT}
      PORT: 4002
      JWT_SECRET: ${JWT_SECRET}
      LOG_LEVEL: info
      SENTRY_DSN: https://a34ae347621946bf8acded18e5b7d4b8@o420233.ingest.sentry.io/5338131
      ENABLE_ANALYTICS: "true"
      REDIS_URL: redis-service:6379
      REDIS_PASSWORD: ${REDIS_PASSWORD}
      BB_ADMIN_USER_EMAIL: ${BB_ADMIN_USER_EMAIL}
      BB_ADMIN_USER_PASSWORD: ${BB_ADMIN_USER_PASSWORD}
      PLUGINS_DIR: ${PLUGINS_DIR}
    depends_on:
      - worker-service
      - redis-service
#    volumes:
#      - /some/path/to/plugins:/plugins

  worker-service:
    restart: unless-stopped
    image: budibase.docker.scarf.sh/budibase/worker
    container_name: bbworker
    environment:
      SELF_HOSTED: 1
      PORT: 4003
      CLUSTER_PORT: ${MAIN_PORT}
      JWT_SECRET: ${JWT_SECRET}
      MINIO_ACCESS_KEY: ${MINIO_ACCESS_KEY}
      MINIO_SECRET_KEY: ${MINIO_SECRET_KEY}
      MINIO_URL: http://minio-service:9000
      APPS_URL: http://app-service:4002
      COUCH_DB_USERNAME: ${COUCH_DB_USER}
      COUCH_DB_PASSWORD: ${COUCH_DB_PASSWORD}
      COUCH_DB_URL: http://${COUCH_DB_USER}:${COUCH_DB_PASSWORD}@couchdb-service:5984
      SENTRY_DSN: https://a34ae347621946bf8acded18e5b7d4b8@o420233.ingest.sentry.io/5338131
      INTERNAL_API_KEY: ${INTERNAL_API_KEY}
      REDIS_URL: redis-service:6379
      REDIS_PASSWORD: ${REDIS_PASSWORD}
    depends_on:
      - redis-service
      - minio-service
      - couch-init

  minio-service:
    restart: unless-stopped
    image: minio/minio
    volumes:
      - minio_data:/data
    environment:
      MINIO_ACCESS_KEY: ${MINIO_ACCESS_KEY}
      MINIO_SECRET_KEY: ${MINIO_SECRET_KEY}
      MINIO_BROWSER: "off"
    command: server /data --console-address ":9001"
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:9000/minio/health/live"]
      interval: 30s
      timeout: 20s
      retries: 3

  proxy-service:
    restart: unless-stopped
    ports:
      - "${MAIN_PORT}:10000"
    container_name: bbproxy
    image: budibase/proxy
    environment:
      - PROXY_RATE_LIMIT_WEBHOOKS_PER_SECOND=10
      - PROXY_RATE_LIMIT_API_PER_SECOND=20
    depends_on:
      - minio-service
      - worker-service
      - app-service
      - couchdb-service

  couchdb-service:
    restart: unless-stopped
    image: ibmcom/couchdb3
    environment:
      - COUCHDB_PASSWORD=${COUCH_DB_PASSWORD}
      - COUCHDB_USER=${COUCH_DB_USER}
    volumes:
      - couchdb3_data:/opt/couchdb/data

  couch-init:
    image: curlimages/curl
    environment:
      PUT_CALL: "curl -u ${COUCH_DB_USER}:${COUCH_DB_PASSWORD} -X PUT couchdb-service:5984"
    depends_on:
      - couchdb-service
    command: ["sh","-c","sleep 10 && $${PUT_CALL}/_users && $${PUT_CALL}/_replicator; fg;"]

  redis-service:
    restart: unless-stopped
    image: redis
    command: redis-server --requirepass ${REDIS_PASSWORD}
    volumes:
      - redis_data:/data

  watchtower-service:
    restart: always
    image: containrrr/watchtower
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
    command: --debug --http-api-update bbapps bbworker bbproxy
    environment:
      - WATCHTOWER_HTTP_API=true
      - WATCHTOWER_HTTP_API_TOKEN=budibase
      - WATCHTOWER_CLEANUP=true
    labels:
      - "com.centurylinklabs.watchtower.enable=false"

volumes:
  couchdb3_data:
    driver: local
  minio_data:
    driver: local
  redis_data:
    driver: local

A simpler run configuration:

docker run -d -t --name=budibase -p10000:80 -v /local/path/data:/data \ --restart unless-stopped budibase/budibase:latest

This downloads a LOT of images but the command is short:

A lot of images and containers are built and activated when this is called:

It will first ask you for an admin username / password and then you can login:

Main Screen (there are a LOT of features here)..

There are a LOT of options and features for this:  https://www.youtube.com/watch?v=a53SWEMW2S0
